SANY STC500E Mobile Truck Crane
Model:
STC500E
Category:
Lifting Machinery
Product:
Tower Crane
Brand Name:
SANY
Dimension (mm):
13960*2650*3700
Operating Weight (kg):
6000
Origin:
China
Min Order Quantity:
1
Delivery Time:
15 days
Summary
Counterweight:
3.5 T
Max. Lifting Capacity:
50 T
Max. Boom Length:
43 m
Place of origin:
China
Brand Name:
SANY
Max. Lifting Height:
59.2 m
Specifications
Max. Traveling Speed:
85 km/h
Wheel Formula:
8*4
Available Districts:
Euro 5 available in Pan-Russia
Max. Lifting Moment:
1774 kN·m
Packaging & Shipping
Delivery Lead Time:
7 days for ready goods
Minimum Order:
1
Supply Ability:
10,000 Set/ Sets per Month
Total Quantity In Stock:
Over 5000
Delivery Port:
Any Port In China
Details
ITEM UNIT PARAMETER
dimensions (L*W*H) mm 13960*2650*3700
machine weight kg 39000(without counterweight)
rated load First and second axis load kg 13000
Three and four axis loads kg 26000
engine - YUCHAI
rated power kW/rpm 243/2200
Maximum output torque N.m/rpm 1350/1200~1700
max. traveling speed km/h 90
min. turning radius m 12
approach angle ° 19
departure angle ° 12.5
Maximum grade % 45
Fuel consumption per 100 kilometers L 37
rated load ton 50
Maximum lifting moment base boom kN.m 1644
Fully-extended boom kN.m 1098
Outrigger span Longitudinal m 7.5
Lateral m 6.05
Boom length Base boom m 11.7
Fully-extended boom m 45
Fully-extended boom + Jib m 61
Maximum speed of main winch single rope (no load) m/min 140
Maximum speed of single rope of auxiliary winch (no load) m/min 140
Boom full extension/retraction time s 100/120
Boom full lift/lower time s 50/60
Swing speed r/min 0-2.5
